4. Product Features

1. 7-inch medical-grade LCD touch screen with high resolution, intuitive interface and smooth operation
2. Integrated compact structure, saving valuable laboratory bench space
3. Low-noise metal housing with high-performance sound insulation interlayer for excellent noise reduction; clean and tidy inner working chamber
4. Intelligent MCU digital circuit board, supporting intermittent pulse mode and continuous running mode
5. Large transparent acrylic observation window for easy cleaning and real-time sample observation
6. Equipped with electric lifting work platform, built-in LED lighting system and UV germicidal disinfection function
7. Ultra-precise time control: ultrasonic ON time, ultrasonic OFF time and total working time adjustable to 0.1 second accuracy
8. Dual operation modes: test mode and formal run mode, with pause & emergency stop functions
9. Intelligent self-diagnosis system: automatic horn matching, real-time frequency tracking, automatic fault alarm & over-load protection
10. Ultrasonic probe made of TC4 medical titanium alloy, featuring high mechanical strength, superior corrosion resistance and excellent heat resistance
11. Aerospace-grade magnesium-aluminum alloy transducer with stable and powerful ultrasonic output performance
12. Factory default English language interface for global users
13. User password lock protection to prevent unauthorized operation by untrained personnel
14. Built-in buzzer for audible working status & fault alerts
15. Built-in storage for up to 256 groups of experimental parameter programs; users can quickly configure, save and recall parameter sets
16. Rear expansion ports reserved for external accessories: manual switch or foot pedal for fine manual operation; compatible with external linked equipment including thermostatic circulator, magnetic stirrer, portable printer and upper computer control system

5. Technical Specifications

1. Display: 7-inch high-definition touch screen
2. Ultrasonic Power: 20–150W
3. Transducer Frequency Range: 20–25 kHz
4. Disruption Volume Range: 0.1–200 mL (matched with optional ultrasonic horns of different diameters)
5. Single Ultrasonic ON Duration: 0.1–99.9 seconds
6. Single Intermittent OFF Duration: 0–99.9 seconds (0s = continuous operation mode)
7. Total Running Time: 0.1–999.9 minutes
8. Power Regulation Mode: Continuous power adjustment or PWM pulse modulation (PWM optional)
9. Temperature Detection: Contact-type temperature sensor
10. Over-Temperature Alarm Range: 0–99.9 ℃
11. Sample Temperature Control Range: 1–99.9 ℃ (thermostatic circulator as optional accessory)
12. Interfaces: Main power port, USB data port, 7-pin aviation connector
13. Optional Matching Ultrasonic Horns: Φ2 mm, Φ3 mm, Φ6 mm
14. Input Power Supply: AC 100–240V universal global voltage
15. Mains Frequency: 50Hz / 60Hz auto-adaptive
16. Net Weight: Approx. 19 kg
17. Overall Instrument Dimension: 345mm × 350mm × 560mm
